RH-20 Rheometer

Ⅰ. Introduction of Shanghai BosinTech RH-20 Rheometer

Key words: Rheometer; Material Property Analyzer; Rotational Rheometer; Torque Rheometer

Rheometers are instruments used to determine the rheological properties of polymer melts, polymer solutions, suspensions, emulsions, coatings, inks, and food products. Divided into rotational rheometer, capillary rheometer, torque rheometer and interface rheometer. Shanghai BosinTech RH-20 rheometer can be used to determine the rheological properties of polymer melts, polymer solutions, suspensions, emulsions, coatings, inks and foods. Shanghai BosinTech RH-20 rheometer is similar to HAAK rheometer, TA rheometer, Anton Paar rheometer, brookfile rheometer, etc., and can be used to observe the internal structure window of polymer materials. The molecular weight and molecular weight distribution of polymer materials can be characterized by the response of different scales of molecular chains in polymer materials, such as plastics, rubbers, and resins. It can quickly, easily and effectively perform quality testing and quality control of raw materials, intermediate products and final products.

Rheological performance testing builds a bridge between the molecular weight, molecular weight distribution, degree of branching and processing properties of polymers. So rheometers provide a direct link to assist users in raw material inspection, process design and product performance prediction.

Ⅱ. Technical parameters of Shanghai BosinTech RH-20 rheometer

1. Minimum torque: 5 nNm

2. Maximum torque: ≥200 mN.m

3. Torque resolution: ≤0.1 nNm

4. Motor inertia: ≤12 μNms

5. Angular displacement resolution: ≤15 nrad

6. Oscillation frequency: 4-10 Hz~100 Hz

7. Maximum normal force: 50 N

8. Electric heating concentric cylinder temperature range: room temperature -300 ℃

9. Liquid temperature control concentric cylinder temperature range: -30-200 ℃

10. Maximum speed: ≥4500 rpm

Ⅲ. Main functions and application scope of Shanghai BosinTech RH-20 rheometer

Shanghai BosinTech RH-20 rheometer can be used in a variety of detections in food (liquid, solid, gel, dispersion), fermentation, chemical, pharmaceutical, textile, agricultural and other industries. It is suitable for macromolecular affinity such as protein and polysaccharide. Determination of rheological properties of hydrocolloids, including rheological studies of fluids, soft solids, polymers, gels and dispersions of any viscosity. Since the rheological properties of food materials have an important relationship with the texture stability of food and processing process design, etc., so through the study of rheological properties of food and chemical materials, we can understand the composition, internal structure and molecular morphology of food and chemical materials, which can provide convenience and basis for product formulation, processing process, equipment selection and quality testing, etc. Through rheometer testing, quality monitoring of food and medicine, food R&D and food engineering design can be carried out.

1. Shanghai BosinTech RH-20 rheometer used in polymer field

Shanghai BosinTech RH-20 rheometer applied to the study of the gelation and melting characteristics of PVC plastisol by micro-suspension method;

Shanghai BosinTech RH-20 rheometer applied to the standard rheological curve of PVC materials;

Shanghai BosinTech RH-20 rheometer is used in polymer research. By recording the reaction torque generated by the material to the rotor or screw during the mixing process and the temperature change with time, the dispersion performance and flow behavior of the material during processing can be studied. and structural changes (crosslinking, thermal stability, etc.), and can also be used as an effective means of production quality control;

Shanghai BosinTech RH-20 rheometer is applied to the preparation of r-PET/ABS composites and its crystallization kinetics study.

2. Shanghai BosinTech RH-20 rheometer used in food watershed

Shanghai BosinTech RH-20 rheometer applied to the research of rheological properties of sauce products;

Shanghai BosinTech RH-20 rheometer is used in food formulation and process research;

The application of Shanghai BosinTech RH-20 rheometer in the quality analysis of steamed bread;

Shanghai BosinTech RH-20 rheometer applied to the research on the morphology of corn starch with different chain/branch ratio and its gelatinization with/without shearing force;

Application of Shanghai BosinTech RH-20 rheometer to the study of granule morphology and pasting characteristics of fern starch;

Comparison of rheological properties of Shanghai BosinTech RH-20 rheometer applied to ketchup products;

Shanghai BosinTech RH-20 rheometer applied to the process research of blueberry fermentation by-products to make low-sugar jam;

Shanghai BosinTech RH-20 rheometer applied to the viscosity determination of chocolate and quality control of chocolate raw materials by rotary rheometer;

Shanghai BosinTech RH-20 rheometer is used in the application of rotational rheometer in oil research.

3. Shanghai BosinTech RH-20 rheometer used in the field of cosmetics

Shanghai BosinTech RH-20 Rheometer is applied to the study of gel rheological properties;

Shanghai Baosteel RH-20 Rheometer for emulsion system rheology research;

Shanghai Baosteel RH-20 Rheometer is used to study the rheological properties of surfactants;

Shanghai Baosteel RH-20 Rheometer for water-in-oil emulsion cosmetics;

Preliminary study on the rheological properties of toothpaste with Prulan polysaccharide by Shanghai BosinTech RH-20 rheometer;

4. Shanghai BosinTech RH-20 rheometer is used in the field of colloids

Shanghai BosinTech RH-20 rheometer applied to the rheological research method of polymer hydrogel materials;

Shanghai BosinTech RH-20 rheometer applied to the basic research on the rheological properties of synthetic hydrogels and related biomaterials;

Shanghai BosinTech RH-20 rheometer applied to the preparation and performance of new natural polymer polysaccharide smart hydrogel biomaterials;

Shanghai BosinTech RH-20 rheometer is applied to study the viscoelasticity and stability of natural silk sericin protein at different oil/water interfaces.

5. Shanghai BosinTech RH-20 rheometer applied in oil field

Shanghai BosinTech RH-20 rheometer applied to the application of oil drilling mud testing;

Shanghai BosinTech RH-20 Rheometer applied to the study of rheological properties of biodegradable materials;

Shanghai BosinTech RH-20 rheometer applied to the evaluation of asphalt properties;

Application of Shanghai BosinTech RH-20 Rheometer to thixotropy experiments on crude oil containing wax;

Shanghai BosinTech RH-20 rheometer applied to the rheology of colloidal liquid foam;

Shanghai BosinTech RH-20 rheometer applied to the rheology of low-temperature gel-like blocking agent solution.
